PM42-B90K2/2K constant voltage input/constant voltage output LED push button dimmer/adjust color temperature constant voltage input output LED push button dimmer/adjust color temperature
price
$3.50 - $4.00 / piece
PM42-B90K2/2K
1 piece
Shenzhen
Color
White
Quantity
A 12V dimmer switch is an electrical device that controls the brightness of 12V lighting systems.
- Warranty(Year):2-Year
- Lighting solutions service:auto CAD layout
- Place of Origin:Guangdong, China
- Brand Name:PIMI
- Type:MANUAL SWITCH
- Max. Load Power:36W
- Product name:LED push button dimmer Switch
- input voltage:12-36V DC
- output voltage:12-36V DC
- output current:1000-3000mA
- output power:36W max
- Voltage:12-36V DC
PM42-B90K2/2K
Constant voltage input/constant voltage output LED push button dimmer/adjust color temperature
| Model | Input voltage | A Output voltage | A Output current | B Output voltage | B Output current | Dimming mode | Approval |
| PM42-B90K2-1000 | 12-36V | 12-36V | 1000mA | 12-36V | 1000mA | 3-step dimming continuous dimming dimming and adjust CCT | CE |
| PM42-B90K2-2000 | 12-36V | 12-36V | 2000mA | 12-36V | 2000mA | CE | |
| PM42-B90K2-2500 | 12-36V | 12-36V | 2500mA | 12-36V | 2500mA | CE | |
| PM42-B90K2-3000 | 12-36V | 12-36V | 3000mA | 12-36V | 3000mA | CE | |
| PM42-B902K-1000 | 12-36V | 12-36V | 1000mA | 12-36V | 1000mA | CE | |
| PM42-B902K-2000 | 12-36V | 12-36V | 2000mA | 12-36V | 2000mA | CE | |
| PM42-B902K-2500 | 12-36V | 12-36V | 2500mA | 12-36V | 2500mA | CE | |
| PM42-B902K-3000 | 12-36V | 12-36V | 3000mA | 12-36V | 3000mA | CE |
Use together PM20-A series switch
With indicator light
DImensions(L*W*H): 24*70*11mm, 95*11*7mm
Dimming mode: touch continuous dimming and 3-stage color temperature adjustable
touch continuous dimming and continuous adjusting color temperature
Standards: EN 55015
EN 61000
EN 61547
EN 61058
